Edimax Pro industrial switch series is designed for easy, flexible deployment and management with ever better cost efficiency by reducing downtime, extending system lifecycle and lowering maintenance costs with more features as below but not last.
Ideal solution for industrial networks such as automotive, factory automation, oil and gas, mining, military, transportation, substation, energy and outdoor applications of railways, roads, tunnels, smart cities, city surveillance and traffic monitoring.
HARDWARE | |
Ports | 8 x RJ45 10/100/1000Base-T Gigabit PoE+ ports 4 x SFP 1000Base-X slots 1 x Console port for CLI management 1 x USB 2.0 port for firmware update, configuration backup, restore, boot up and system log storage |
Button | 1 x Multiple function reset button |
Transmission Method | Store and forward |
LED Indicators | Per Port: Link/ActPer unit: PWR1, PWR2, Fault, Ring Master, Ring State Port: Link/Active with highest speed (green), low speed (amber) PoE: Output power |
Power Input | Redundant Dual DC 48V-57V |
Power Consumption | Max. 18.24W (system power consumption) 0.38A@48VDC |
Power Connection | 1 x Removable 4-connect terminal block |
Digital Input | 1 x Isolated input from the electronics +13 to +30V fro state “1” -30 to +3V for state “0” Max. input current: 8mA |
Total Power Budget | 259W (system power consumption max. 18.24W) |
Reserve Polarity Protection | Yes |
Overload Current Protection | Yes |
Alarm Contact | 1 x Relay output with current carrying capacity of 1A@24VDC |
Fan | Fanless |
Housing | Ruggedized aluminum alloy case, IP30-rated |
Installation | DIN-rail mounting or optional wall mounting |
Dimensions (L x W x H) | 72.2 × 145 × 113 mm |
Weight | 0.75 kg |
PERFORMANCE | |
Switching Capacity | 24Gbps |
MAC Address | 16K |
Buffer Memory | 12M bit |
Jumbo Frames | 16K |
Filtering / Forwarding Rates | 1000Mbps port – 1,488,000pps 100Mbps port - 148,800pps 10Mbps port - 14,880pps Max. 17.856Mpps |
POWER OVER ETHERNET | |
Standard | IEEE 802.3af (PoE), IEEE 802.3at (PoE+) |
Power Output | Up to 30W per port |
Pin Assignment | 1/2(+), 3/6(-) End-Span (mode A) |
Total PoE Power Budget | Max. 240W |
Power Feeding Detecting Capability on PD | Yes |
PD Classification | Yes |
Power Management (Per Port) | Enable/Disable PoE Priority setting Power level setting Overloading protection PoE PD alive check PoE scheduling |
SMART FEATURES | |
Quality of Service (QoS) | Eight queues on each port WRR, SP, WRR+SP queue scheduling algorithms Re-marking of the 802.1p priority and DSCP priority |
Class of Service (CoS) | IEEE 802.1p class of service (SPQ, WRR) Port-based CoS IP TOS precedence 802.1p VLAN Information based CoS DSCP based CoS TCP/UDP Based CoS |
Spanning Tree | IEEE 802.1d Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Trees (MSTP) |
VLAN | Up to 200 VLANs and 4096 VLAN IDs 802.1Q tag-based VLAN Port-based VLAN Q-in-Q |
Link Aggregation | IEEE 802.3ad with LACP |
IPV6 | IPv6 over Ethernet (RFC 2464) Dual-stack (RFC 4213) ICMPv6 (RFC 4884) Neighbor discovery (RFC 4861) Auto configuration Static IPv6 address and prefix length Static IPv6 default gateway IPv6 duplicate address detection |
Port Trunking | IEEE 802.3ad LACP Trunk-Static trunk up to 8 trunk groups |
IGMP Snooping | IGMP v1/v2 /V3 snooping (1023 IGMP groups) IGMP Static Multicast Addresses Querier, Immediate Leave |
Mirror | Port mirroring both on ingress and egress traffic |
Security | Storm Control Management system user name/password protection IEEE 802.1x Port-based access control RADIUS (Authentication, Authorization, Accounting) TACACS+ HTTP & SSL (Secure Web) SSH v2.0 (Secured Telnet Session) |
Management | User Interface: Web-based management User Account: Login account configuration Firmware Upgrade: Firmware upgrade by WEB HTTP Syslog: Support event log, error log Command Line Interface (CLI) Telnet Configuration download/upload SNMP (v1/v2/v3) RMON (1, 2, 3 & 9 groups) DHCP (server/Client/Relay/Option82) NTP/LLDP Port Mirroring Industrial Profiles: Modbus TCP, Ethernet/IP |
ENVIRONMENT | |
Temperature | Operating: -40 ~ 75℃ Storage: -40 ~ 80℃ |
Humidity (Non-condensing) | Operating: 10 ~ 95% Storage: 10 ~ 90% |
MTBF (Mean Time Between Failure) | >100,000 hours |
STANDARDS COMPLIANCE | |
Standards | IEEE 802.3 10BaseT Ethernet IEEE 802.3u 100BaseTX Fast Ethernet IEEE 802.3ab 1000BaseT Gigabit Ethernet IEEE 802.3z 1000BaseSX/LX IEEE 802.3af Power over Ethernet (PoE) IEEE 802.3at Power over Ethernet Plus (PoE+) IEEE 802.3x Full-duplex and flow control |
CERTIFICATIONS | |
EMI | FCC Part 15 Subpart B Class A CE EN 55032 Class A |
EMS | IEC61000-4-2 (ESD) IEC61000-4-3 (RS) IEC61000-4-4 (EFT) IEC61000-4-5 (Surge) IEC61000-4-6 (CS) IEC61000-4-8 (Magnetic Field) |
EMC | 61000-6-2 61000-6-4 |
Green | RoHS Compliant |
Vibration | IEC60068-2-6 |
Shock | IEC60068-2-27 |
Free Fall | IEC60068-2-32 |
