N150 Wi-Fi 4 Nano USB Adapter

EW-7811Un V2

  • N150: Compliant with IEEE 802.11b/g/n with a data rate of up to 150Mbps at 2.4GHz
  • Small and Stylish Design: Extremely small size
  • Wi-Fi Security: High level Wi-Fi security is supported with WPA3-SAE (Personal), WPA2, WPA,  and WEP
  • Easy Connection: Supports the software WPS (Wi-Fi Protected Setup)
  • Plug-and-Play: Supports Plug-and-Play on Windows system
  • Green WLAN: Power-saving mechanism saves power up to 50%
  • Supported OS: Windows, macOS, and Linux
  • Application: Good to use on laptops and desktops. Moreover, you can integrate it into embedded system to develop diverse IoT services.
Share







Wi-Fi 4 Nano USB Adapter

EW-7811Un V2

















Tiny and Stylish

Can be easily plugged into any laptop without sacrificing portability and looks. Furthermore, it is designed with details in mind, such as not blocking other ports or be in the way of other USB devices/cables.

Tiny and Stylish

Wide Compatibility

Tested with Windows and Linux, you will sure find it easy, powerful and smooth to use.

Wide Compatibility
Supports WPS | Wi-Fi Protected Setup (via software)

Supports WPS
Wi-Fi Protected Setup

Wi-Fi Protected Setup (WPS) is a standard for easy and secure establishment of wireless networks.  With a few clicks, your wireless network and router are immediately secured.

WPA3

Supports WPA3
Cutting edge security protocol

WPA3 provides cutting-edge security protocols to your networking equipment. The EW-7811Un V2 supports the latest WPA3 standards for strong security standards as well as simplicity.

Green WLAN | Reduces power consumption

Green WLAN
Reduces power consumption

The EW-7811Un V2 cleverly adjusts its power output according to the transmission distance and CPU offload as well as drastically reduces power consumption when the connection is in idle.

Embedded Wireless Adapter Solution for Industrial IoT
Tested by Millions

For over 10 years, millions of users and devices count on EDIMAX adapters to connect to the internet. Choose EDIMAX for reliability and ease-of-use.

Embedded Wireless Adapter Solution for Industrial IoT
Embedded Wireless Adapter Solution for Industrial IoT
EDIMAX EW-7811Un V2 Wi-Fi 4 Nano USB Adapter, Embedded Wireless for IoT, Manufacturer, smart factory, warehouse, retailer

Manufacturer, Warehouse, Retailer

Industrial IoT Devices, Factory, Automation Robot, Portable RFID Reader, Barcode , People Counter, Receipt Machine, and etc.

EDIMAX EW-7811Un V2 Wi-Fi 4 Nano USB Adapter, Embedded Wireless for IoT, Smart Agriculture

Smart Agriculture

Autonomous Robots, Drones or UAVs, Sensors and the IoT from Temperature, Water Level, Water Pressure, Solar Radiation, Leaf Moisture and Stem Diameter, and etc.

EDIMAX EW-7811Un V2 Wi-Fi 4 Nano USB Adapter, Embedded Wireless for IoT, healthcare, medica equipment

Healthcare

Glucometer, Thermometer, Sphygmomanometer, Oximeter, Diagnostic Devices, Microscope, and etc.

EDIMAX EW-7811Un V2 Wi-Fi 4 Nano USB Adapter, Embedded Wireless for IoT, business commeical device, smart home appliances

Commerce, Entertainment, Sport Tech

Commercial Air Purifier, Drone, Business Printer, Coffee System, Creative Robots, Golf Swing Analyzers, Smart Home Appliances, and etc.


Share


​

SPECIFICATIONS

HARDWARE ​
Interface
 •1 x USB 2.0 Type A
LED Indicator    •1 x Link/Activity LED
Antenna
•Internal Antennas x 1 (1T1R)
Dimensions
•7.1 (H) x 14.9 (W) x 18.5 (D) mm
Weight
•2g
WIRELESS
Standard
•2.4GHz: IEEE 802.11b, 802.11g, 802.11n
Frequency Band
 •2.4000 - 2.4835GHz*
*Subject to local regulations
Maximum Transmit Power
•11b : 17±1.5dBm
•11g : 16±1.5dBm
•11n : 13±1.5dBm
Maximum Data Speed
•11b: 1/2/5.5/11Mbps;
•11g: 6/9/12/24/36/48/54Mbps
•11n (20MHz): MCS0-07, up to 72Mbps
•11n (40MHz): MCS0-07, up to 150Mbps
Security
•WEP 64/128-bit, WPA, WPA2
​•Software WPS Configuration
OTHERS
Certification    •CE (DoC), FCC, RoHS
Environmental Condition
•Operating Temperature: 32~104°F (0~40°C)
•Storage Temperature: -4~140°F (-20~60°C)
•Operating Humidity: 0~90% (NonCondensing)
•Storage Humidity: Max. 95% (NonCondensing)
System Requirement
•Windows 7/8/8.1/10 or above
•Mac OS 10.13 or above
•Linux OS (Fedora & Ubuntu)
Installation    •Multi-language easy setup wizard with auto run configuration
Package Content

•Quick Installation Guide
•Wi-Fi USB Adapter






*Maximum performance, actual data rates, and coverage will vary depending on network conditions and environmental factors.
*Actual viewing resolution and frame rate of network cameras depend on connection speed.
*Product specifications and design are subject to change without notice.
