10 Gigabit Ethernet SFP+ PCI Express Server Adapter

EN-9320SFP+

  • PCI Express rev. 2.0 Specification x4 interface
  • Converts a PCIe slot into an SFP+ fiber slot
  • Compatible with standard SFP+ modules
  • 16K jumbo frames
  • IP, TCP, UDP checksum offloading
  • Reduced CPU utilization and improved through
  • Supports IEEE 802.1Q VLAN ID tagging and IEEE 802.1q QoS
  • Low profile bracket included

    Edimax 10GbE logo


The EN-9320SFP+ is a 10 Gigabit Ethernet SFP+ PCI Express Server Adapter designed for the high-speed PCI Express bus architecture. This meets the high-performance requirements such as large file transfers and HD video editing, which utilizes high-performance shared storage system to have improved server efficiency and network performance.

Combining the EN-9320SFP+ with SFP+ modules (Edimax MG-10G Series), your system is offered greater flexibility in optional fiber distances, and superior performance in fast and reliable 10Gbps network access that eliminates existing bottlenecks in current 32 and 64-bit PCI bus architectures. The EN-9320SFP+ is an ideal addition to your server or workstation to complement the requirements of low latency, high bandwidth, and low CPU overhead.

10GbE Superior Network Speed

By sporting a 10 Gigabit SFP+ interface, the EN-9320SFP+ is capable of providing 10 times better performance than existing Gigabit transmissions.

Advanced Features & Security

The EN-9320SFP+ features 802.1Q Virtual LAN (VLAN) tagging for Ethernet frames providing network management with a flexible and more secure environment. Moreover the card supports advanced features for best performance such as 16K Jumbo Frame and IEEE 802.3x Flow Control.​

Enhanced CPU & Network Efficiency

The EN-9320SFP+ card supports TCP, UDP, and IP checksum offloading – Free up resources to be allocated to handle other tasks without compromising network speed (of up to 10Gbps).

Greater Flexibility. Greater Distance.

The EN-9320SFP+ connects your server or workstation directly to a fiber network to boost the extension range from 300 meters to up to 10 kilometers (depends on the SFP+ module).

Application Diagrams

​Other 10GbE Products

Edimax Pro XGS-5008

Web Smart Switch

XGS-5008

PCI Express Adapter

EN-9320TX-E

Adapter SFP+ Module

MG-10G Series



SPECIFICATIONS
HARDWARE
Attachment Interface  PCI Express Rev. 2.0 Specification x4 Interface
Media Interface SFP+ Connector
Optical Module Options LR, SR
Jumbo Frame 16K Bytes
LED Indicators ​ LNK / ACT Per Port
Typical Power Consumption 4 Watts
SOFTWARE
OS Compatibility Windows Server 2012 R2, Server 2012, Server 2008R2, Server 2016
Windows 10, Windows 8.1, Windows 7 (32/64-bit)
Linux 4.x, 3.x, Linux 2.6.x (32/64-bit)
Mac OS X 10.10.X (Yosemite)
Mac OS X 10.11.x (EL Captain)
MAC OS Sierra (10.12.x)
VMware ESXi 6.0, 5.5, 5.1
Microsoft Hyper-V
Linux KVM
Oracle VirtualBox
ENVIRONMENT
Temperature Operating: 0 - 50 ℃
Storage: -40 - 85℃
Humidity (Non-condensing) Operating: 5 - 95%
Storage: 5 - 95%
Physical Characteristics
Dimensions (W x D) 82 x 62 mm
Weight 65g
Standards Compliance
Standards and Protocols IEEE 802.3ae: 10Gbps Ethernet
IEEE 802.3x: Flow Control and Back Pressure
IEEE 802.2ad: Link Aggregation
IEEE 802.1Q VLAN support
RFC2819 RMON MIB statistics
Certifications FCC, CE
*Maximum performance, actual data rates, and coverage will vary depending on network conditions and environmental factors.
*Actual viewing resolution and frame rate of network cameras depend on connection speed.
*Product specifications and design are subject to change without notice.
